JL-240XHA

NEMA Fixed Twist-lock dimming receptacle（Gold pad narrowed version）

All the JL-240XHA series photocontrol receptacles were designed for the lanterns those intended to have an ANSI C136.10 receptacle to fit a twist-lock photocontrol. This series conform newly published ANSI C136.41 to allow a LED lamp multi-controlled through the receptacle.
This series offers 4 gold-plated low voltage pads on the top surface to fit photocontrol has ANSI C136.41 conforming spring contacts, and offers 4 wiring leads at rear side for signal connection.

Features

Glass-Fiber strongen PBT
Gilded Pads made from phophor bronze Nickel plated and gilded over 0.7um
Gold plating per ASTM B 588
Silicone gasket offered
Gold pad narrowed for competitive cost

Specifications

Model No.	JL-240XH
Applicable Volt Range	0~480VAC
Rated Frequency	50/60Hz
Load Rating	15A
Signal Control	0-30 VDC, 250 mA Max
Lead	16AWG/14AWG 6" min
Ambient Temperature	-40°C ~ +70°C
Related Humidity	96%
Outdoor Wiring Cable	●
Certifications	ANSI C136.41-2013

Installation

Disconnect the power supply
Connect the socket according to the diagram below
The arrow at the top of the socket indicating the north is used to help determine the correct direction
Adjust the socket position by loosening the screws and secure it after repositioning

Wiring diagram
